Features
- Integrated wet cup ensures extended pump life!!
- Reliability - Hydraulic pump motor is the fluid handling professional's path to trouble-free pumping
- Durability - Improved top plug seal design to optimize and maintain motor seal integrity
- Versatility - Lower pump as adaptable to hydraulic or pneumatic motor power source
- Environmentally Sound - Hydraulic motor produces lower noise emissions than pneumatic motor
- Serviceability - Simple two piece modular motor base permits easy access to the rod seal and wiper assembly
Materials of Construction
- Lower Pump Material: 316 Stainless Steel
- Plunger Material: 17-4 Stainless Steel
Packing Options
- UHMW-PE
Accessories
- 61938-1 Wall Mount Bracket
- 66333-B Wet Sol
- 65138 Floor Mount
- 67136 Floor Mount Adapter
- 637306-X43 Lower End Repair Kit
| RATIO | 3.3 :1 |
|---|---|
| Hydraulic Inlet Pressure Range psi (bar) | 50 - 1,200 (3.4 - 82.8) |
| Fluid Pressure Range psi (bar) | 165 - 3,960 (11.4 - 273.1) |
| Max Cycles/Minute | 50.0 |
| Displacement/Cycle cu in (cm3) | 7.4 (121.2) |
| Cycles/gal (L) | 31.1 (8.2) |
| Flow @ 50 Cycles gpm (L/min) | 1.6 (6.1) |
| Maximum Hydraulic Temp Limit | 130˚ F (54˚ C) |
