Features
- Integrated wet cup ensures extended pump life!!
- Reliability - Hydraulic pump motor is the fluid handling professional's path to trouble free pumping
- Durability - Fewer seal points within hydraulic motor for fewer problems
- Versatility - Stainless construction permits use with a wide range of fluids and applications
- Environmentally Sound - Hydraulic motor produces lower noise emissions than pneumatic motor
- Serviceability - Tie rod construction and modular design for ease of service and repair
Materials of Construction
- Lower Pump Material: 400 Stainless Steel
- Plunger Material: 15-5 Stainless Steel (hard chrome plated)
Packing Options
- UHMW-PE
- Mineral-filled PTFE
- UHMW-PE/PTFE staggered (upper), UHMW-PE (lower)
- PTFE/UHMW-PE (upper),PTFE (lower)
Accessories
- 61938-1 Wall Mount Bracket
- 66333-B Wet Sol
- 65138 Floor Mount
- 67136 Floor Mount Adapter
- 637211-XX3 Lower End Repair Kit
| RATIO | 0.8 :1 |
|---|---|
| Hydraulic Inlet Pressure Range psi (bar) | 50 - 2,000 (3.4 - 13.9) |
| Fluid Pressure Range psi (bar) | 40 - 1,600 (4.1 - 110.3) |
| Max Cycles/Minute | 50 - 2,000 (3.4 - 13.9) |
| Displacement/Cycle cu in (cm3) | 59.6 (976.6) |
| Cycles/gal (L) | 3.9 (1.0) |
| Flow @ 50 Cycles gpm (L/min) | 12.9 (48.8) |
| Maximum Hydraulic Temp Limit | 130˚ F (54˚ C) |
