Features
- Reliability- Multiple packing options permit maximum fluid compatibility
- Durability- Ultra Coated (ceramic) Plunger Rod and Tube for superior abrasion resistance
- Versatility- High flow rate excellent for large transfer or fluid recirculation
- Environmentally Sound- Optional muffler ensures pump meets OSHA specifications
- Serviceability- Modular design for ease of repair
Materials of Construction
- Lower Pump Material: CF8M Stainless Steel
- Plunger Material: 17-4 Stainless Steel (Ultra-coated)
Packing Options
- UHMW-PE
- UHMW-PE / PTFE staggered (upper), UHMW-PE (lower)
- PTFE / UHMW-PE staggered (upper), Virgin PTFE (lower)
Accessories
- 61937-1 Wall Mount
- 667187-2 Mounting Post
- 637315 Air Section Service Kit
- 637318-X4B Lower End Repair Kit
| RATIO | 0.2 :1 |
|---|---|
| Hydraulic Inlet Pressure Range psi (bar) | 50 - 1,200 (3.4 - 82.8) |
| Fluid Pressure Range psi (bar) | 10 - 278 (0.6 - 19.2) |
| Max Cycles/Minute | 50.0 |
| Displacement/Cycle cu in (cm3) | 103.6 (1,697.6) |
| Cycles/gal (L) | 2.2 (0.5) |
| Flow @ 50 Cycles gpm (L/min) | 22.4 (84.9) |
| Maximum Hydraulic Temp Limit | 130˚ F (54˚ C) |
