Features
- Reliability - Self-lubricating, eliminating downtime
- Durability - Hard chrome plated plunger improves abrasion resistance
- Versatility - Multiple mounting configurations & materials of construction for your application needs
- Environmentally Sound - Reduced noise level
- Serviceability - Minimal part count combined with Tie Rod construction for simple, efficient repairs
Materials of Construction
- Lower Pump Material: Carbon Steel (hard chrome plated)
- Plunger Material: 17-4 Stainless Steel
Packing Options
- UHMW-PE/Leather staggered, multiple wave spring
Accessories
- 66999-B Wet Sol
- 65138 Floor Mount
- 67136 Floor Mount Adapter
- 637071-XX3-B Lower End Repair Kit
| RATIO | 2:1 |
|---|---|
| Hydraulic Inlet Pressure Range psi (bar) | 50 - 1,200 (3.4 - 82.8) |
| Fluid Pressure Range psi (bar) | 100 - 2,400 (6.9 - 165.5) |
| Max Cycles/Minute | 50.0 |
| Displacement/Cycle cu in (cm3) | 12.5 (204.8) |
| Cycles/gal (L) | 18.5 (4.8) |
| Flow @ 50 Cycles gpm (L/min) | 2.7 (10.2) |
| Maximum Hydraulic Temp Limit | 130˚ F (54˚ C) |
